| AXLE WEIGHTS (KG) | |||
| UK standard vehicle plated weights (kg) | GVW | 7500 | |
| GTW (Standard) | 8250 | ||
| GTW (Optional) | 11000 | ||
| UK Axle design weights (kg) | Front | 3100 | |
| Rear | 5800 | ||
| WEIGHTS (KG) | |||
| Cab type | day | ||
| Tail lift type | Tuckaway | ||
| Wheelbase | WB | 4475 | |
| Vehicle Mass Unladen | Front | 2034 | |
| Rear | 2500 | ||
| Total | 4534 | ||
| GVW | 7500 | ||
| Payload Allowance | 2966 | ||
| Max. Permissible Trailer Weight | 3500 | ||
| DIMENSIONS (MM) | |||
| Overall length | 8200 | ||
| Body Length | OAL | Internal Body Length | 6069 |
| Body Width | OVW | External Body Width | 2439 |
| Body Height | OH | Body Height (side aperture) | 2286 |
| FEATURES | |
| Underframe | Galvanised steel runners, galvanised cross bearers, galvanised steel side raves, cross bearers @ 16” pitch, lift up alloy side guards |
| Rear aperture | Rear barn doors with external locking gear |
| Flooring | 18mm wisadeck floor |
| Lighting | 2 interior LED lights with PIR sensor, side and rear LED marker lights to current lighting regulations |
| Roof | GRP one-piece roof complete with bonded roof sticks, ridge pole and load restraint straps |
| Curtains | Stainless steel locking buckles and curtain tensioners each side |
| Options included | Air deflector and side collars. V-Grove side rave with lift up lashing points. Pull out ladder step. |
| Tail lift | DHOLLANDIA 1000kg tuck away tail lift with 1050mm deep platform trolley stops and wander lead control |
| CAB EXTERIOR | CAB INTERIOR | ||
| Type | Hexapod, white all-steel with roof outline markers. | Features | Flame-resistant interior trim. Vinyl floor matting. Pillar mounted entrance grab handles both sides. Driver and passenger SRS airbags |
| Features | Manual tilt to 45 deg. Tinted windscreen. Chrome radiator grille. Plastic resin non-slip entry steps. 90 deg. opening doors. Zinc galvanised frame structure. Steel reinforced composite front bumper with fog and daytime running lamps. Two halogen head lamps with indicators. Front mudguards with spray suppression. Aluminium rear under run bar protection. (R58.03) | Seats: Features: | Driver’s fully adjustable suspension seat with head restraint. Dual split passenger seat, folding back centre with tray. Driver and outer passenger retractable diagonal seat belts, with pretensioner. Centre seat lap belt. 4 seat passenger (crew cab) with lap belts. |
| Vision: Features: | Large foldable, heated mirrors. Interior rear view mirror on collapsible mounting. Driver and passenger sun visors. Deep cut side windows to reduce blind spots. Electric windows front and rear with driver control and lock. | ||
| SAFETY AND SECURITY | |
| R29 cab strength | Complies with ECE-R29 cab strength standard. |
| Central locking | Central locking with remote keyless entry and immobiliser |
| Lane departure warning system | Stereo camera monitor, alerts driver with a warning buzzer and LCD monitor |
| Advanced Emergency Braking System (AEBS) | Utilises stereo camera system to reduce collision damage |
| WARRANTY |
| All chassis cabs come with three-year unlimited mileage warranty and roadside assistance as standard. Curtainside bodes come with the bodybuilder’s 12 month warranty.Terms and conditions apply. |
| Isuzu backed Repair and maintenance contracts available upon request |
