Provisional Dimensions (mm) | |||
---|---|---|---|
Wheelbase | WB | 3365 | 3815 |
Overall Length | OAL | 6100 | 6750 |
Overhang - Front | FOH | 1110 | 1110 |
Overhang - Rear | ROH | 1595 | 1795 |
Cab Gap | CB | 157 | 157 |
C/L Front Axle to Rear of Cab | CA | 573 | 573 |
Recommended Body Length | BL | 4267 | 4876 |
Chassis Frame Width | 850 | 850 | |
Recommended Body Width | 2286 | 2286 | |
Recommended Max Body Width | 2500* | 2500* | |
Cab Width | OW | 2040 | 2040 |
Overall Height (Unladen) | OH | 2230 | 2230 |
Chassis Height (Unladen) | EH | 740 | 740 |
Minimum Road Clearance | HH | 175 | 175 |
Track - Front | AW | 1680 | 1680 |
Track - Rear | CW | 1525 | 1525 |
Rear Axle Width | BW | 2040 | 2040 |
Provisional Weights (kg) | |||
---|---|---|---|
Wheelbase | WB | 3365 | 3815 |
Cab type | day | day | |
Vehicle Mass Unladen | Front | 1591 | 1666 |
Rear | 884 | 870 | |
Total | 2475 | 2536 | |
GVW | 6500 | 6500 | |
Max. Permissible Trailer Weight | 3500 | 3500 | |
Payload Allowance (Body & Payload for Chassis Cab) | 4025 | 3964 |
CAB FEATURES | |||
CAB EXTERIOR | CAB INTERIOR | ||
Type | Hexapod, white all-steel with roof outline markers | Features | Flame-resistant interior trim. Vinyl floor matting. Pillar-mounted entrance grab handles both sides. Driver and passenger SRS airbags. |
Features | Manual tilt to 45 deg. Tinted windscreen. Chrome radiator grille. Plastic resin non-slip entry steps. 90 deg. opening doors. Zinc galvanised frame structure. Steel reinforced composite front bumper with fog and daytime running lamps. Two halogen Steel-reinforced composite front bumper with fog and daytime running lamps. Two halogen head lamps with indicators. Front mudguards with spray suppression. Aluminium rear under run bar protection. (R58.03) | Seats: Features: | Driver’s fully adjustable suspension seat with head restraint. Dual split passenger seat with folding back centre with tray. Driver and outer passenger retractable diagonal seat belts with pre-tensioner. Centre seat lap belt. Upholstery shade upgrade. |
Vision: Features: | Large foldable mirrors. Interior rear-view mirror on collapsible mounting. Driver and passenger sun visors. Deep cut side windows to reduce blind spots. Electric windows with driver control and lock. |
WARRANTY |
All chassis cabs come with three-year unlimited mileage warranty and roadside assistance as standard. Terms and conditions apply. Terms and conditions apply. |
Isuzu backed Repair and maintenance contracts available upon request |
SAFETY & SECURITY | |
R29 cab strength: | Complies with ECE-R29 cab strength standard |
Central locking: | Central locking with remote keyless entry and immobiliser |
Lane departure warning system: | Stereo camera monitor, alerts driver with a warning buzzer and LCD monitor. |
Advanced Emergency Braking System (AEBS): | Utilised stereo camera system to reduce collision damage |
