| Provisional Dimensions (mm) | ||
|---|---|---|
| Wheelbase | WB | 3360 |
| Overhang - Front | FOH | 1100 |
| Cab Gap | CB | 130 |
| C/L Front Axle to Rear of Cab | CA | 463 |
| Chassis Frame Width | 700 | |
| Cab Width | OW | 1770 |
| Overall Height (Unladen) | OH | 2160 |
| Chassis Height (Unladen) | EH | 725 |
| Minimum Road Clearance | HH | 180 |
| Track - Front | AW | 1395 |
| Track - Rear | CW | 1425 |
| Rear Axle Width | BW | 1860 |
| Provisional Weights (kg) | ||
|---|---|---|
| Wheelbase | WB | 3360 |
| Cab type | Day | |
| Vehicle Mass Unladen | Front | 1484 |
| Rear | 1016 | |
| Total | 2500 | |
| GVW | 3500 | |
| Max. Permissible Trailer Weight | 3500 | |
| Payload Allowance (Body & Payload for Chassis Cab) | 1000 | |
| FEATURES | |
| Fully galvanised steel sub frames | Fully galvanised steel tipping gear |
| Multistage direct lift under floor arm | Wander lead control complete with ‘Body Up’ warning light |
| Dual tone audible warning buzzer | Electro hydraulic power pack with thermoplastic oil reservoir |
| Hose burst safety valve | Rubber moulded body rests |
| Heavy duty galvanised gantry with lower alloy infill and upper ‘Isuzu’ pressed infill | 18mm alloy ‘Tippadeck’ heavy duty interlocking floor system |
| Single 400mm high alloy mill finish drop side boards c/w recessed spring catches | 400mm high alloy mill finish tailboard with 2-way hinge assembly and rubber stops |
| Fully galvanised heavy duty removable corner posts | Heavy duty under floor tie points either side |
| Half round thermoplastic mud wings | Integral body prop |
| Safety decals and colour instruction manual | Front and rear marker lights |
| Towbar with pin/ball hitch and seven pin electrics | 400mm LED beacon bar on Toolpod |
| CAB FEATURES | |||
| CAB EXTERIOR | CAB INTERIOR | ||
| Type | Hexapod, white (standard) or metallic grey (optional),all-steel | Features | Flame-resistant interior trim. Vinyl floor matting. Pillar mounted entrance grab handles both sides. Driver and passenger SRS airbags. |
| Features | Manual tilt to 45 deg. Tinted windscreen. Chrome radiator grille. Plastic resin non-slip entry steps. 90 deg. opening doors. Zinc galvanised frame structure. Steel reinforced composite front bumper with fog and daytime running lamps. Two halogen head lamps with indicators. Front mudguards with spray suppression. Keyless door entry and immobiliser. Rear under run bar protection (R58.03) | Seats: Features: | Driver’s fully adjustable suspension seat with head restraint. Dual passenger seat with folding back. Driver and outer passenger retractable diagonal seat belts with pre-tensioner. Centre seat lap belt. Upholstery shade upgrade. |
| Vision: Features: | Large foldable mirrors. Interior rear view mirror on collapsible mounting. Driver and passenger sun visors. Deep cut side windows to reduce blind spots. Electric windows with driver control and lock. | ||
| WARRANTY |
| All chassis cabs come with three-year unlimited mileage warranty and roadside assistance as standard. Terms and conditions apply. Utilitruck bodies come with a three-year unlimited mileage warranty on bodywork components, twelve-months unlimited mileage warranty on all paintwork, from the date of the vehicle’s first registration. Terms and conditions apply. |
| Isuzu backed Repair and maintenance contracts available upon request |
| SAFETY AND SECURITY | |
| R29 cab strength | Complies with ECE-R29 cab strength standard |
| Central locking | Central locking with remote keyless entry and immobiliser |
| Rear bumper | Internal towbar and rear under run bar. |
| Seat belts | Red diagonal and lap belts. |
