Provisional Dimensions (mm) | |||
---|---|---|---|
Wheelbase | WB | 2500 | 3360 |
Overall Length | OAL | 4950 | 6080 |
Overhang - Front | FOH | 1100 | 1100 |
Cab Gap | CB | 130 | 130 |
C/L Front Axle to Rear of Cab | CA | 463 | 463 |
Chassis Frame Width | 700 | 700 | |
Cab Width | OW | 1770 | 1770 |
Overall Height (Unladen) | OH | 2145 | 2145 |
Chassis Height (Unladen) | EH | 730 | 730 |
Minimum Road Clearance | HH | 195 | 195 |
Track - Front | AW | 1395 | 1395 |
Track - Rear | CW | 1395 | 1395 |
Provisional Weights (kg) | |||
---|---|---|---|
Wheelbase | WB | 2500 | 3360 |
Cab type | Day | 3360 | |
Vehicle Mass Unladen | Front | 1345 | 1350 |
Rear | 730 | 815 | |
Total | 2075 | 2165 | |
GVW | 3500 | 3500 | |
Max. Permissible Trailer Weight | 3500 | 3500 | |
Payload Allowance (Body & Payload for Chassis Cab) | 1425 | 1335 |
FEATURES | |
Underframe | Galvanised underframe |
Flooring | 15mm Phenolic one piece floor |
Gantry | Heavy duty galvanised gantry with lower alloy infill and upper ‘Isuzu’ pressed infill |
Wings | Thermoplastic mudguards |
Restraint | Alloy V groove siderave with internal load rings – 3 each side (4 on 3360WB) |
Dropside and tailboard | 400mm single alloy dropsides with lifting catches. 400 mm alloy tailboard with lifting catches. |
Pillars | Galvanised corner pillars |
Towbar | Optional |
CAB FEATURES | |||
CAB EXTERIOR | CAB INTERIOR | ||
Type | Hexapod, white (standard) or metallic grey (option), all-steel | Features | Flame-resistant interior trim. Vinyl floor matting. Pillar mounted entrance grab handles both sides. Driver and passenger SRS airbags. |
Features | Manual tilt to 45 deg. Tinted windscreen. Chrome radiator grille. Plastic resin non-slip entry steps. 90 deg. opening doors. Zinc galvanised frame structure. Steel reinforced composite front bumper with fog and daytime running lamps. Two halogen head lamps with indicators. Front mudguards with spray suppression. Keyless door entry and immobiliser. Rear under run bar protection (R58.03) | Seats: Features: | Driver’s fully adjustable suspension seat with head restraint. Dual passenger seat with folding back. Driver and outer passenger retractable diagonal seat belts with pretensioner. Centre seat lap belt. Upholstery shade upgrade |
Vision: Features: | Large foldable mirrors. Interior rear view mirror on collapsible mounting. Driver and passenger sun visors. Deep cut side windows to reduce blind spots. Electric windows with driver control and lock. |
WARRANTY |
All chassis cabs come with three-year unlimited mileage warranty and roadside assistance as standard. Terms and conditions apply. Dropside bodies come with a three-year unlimited mileage warranty on bodywork components, twelve-months unlimited mileage warranty on all paintwork, from the date of the vehicle’s first registration. Terms and conditions apply. |
Isuzu backed Repair and maintenance contracts available upon request |
SAFETY & SECURITY | |
R29 cab strength: | Complies with ECE-R29 cab strength standard |
Central locking: | Central locking with remote keyless entry and immobiliser |
Rear bumper | Steel rear under run bar |
Seatbelts | Red diagonal and lap belts |
