Provisional Dimensions (mm) | |||||
---|---|---|---|---|---|
Wheelbase | WB | 3410 | 4060 | 4660 | 4990 |
Overall Length | OAL | 6010 | 7000 | 7900 | 8350 |
Overhang - Front | FOH | 1170 | 1170 | 1170 | 1170 |
Overhang - Rear | ROH | 1430 | 1770 | 2070 | 2190 |
Cab Gap | CB | 150 | 150 | 150 | 150 |
C/L Front Axle to Rear of Cab | CA | 556 | 556 | 556 | 556 |
Recommended Body Length | BL | 4500 | 5400 | 6250 | 6750 |
Chassis Frame Width | 840 | 840 | 840 | 840 | |
Recommended Body Width | 2500 | 2500 | 2500 | 2500 | |
Recommended Max Body Width | 2550 | 2550 | 2550 | 2550 | |
Cab Width | OW | 2195 | 2195 | 2195 | 2195 |
Overall Height (Unladen) | OH | 2510 | 2510 | 2510 | 2505 |
Chassis Height (Unladen) | EH | 895 | 930 | 930 | 930 |
Minimum Road Clearance | HH | 185 | 165 | 165 | 165 |
Track - Front | AW | 1795 | 1795 | 1795 | 1795 |
Track - Rear | CW | 1660 | 1660 | 1660 | 1660 |
Rear Axle Width | BW | 2220 | 2220 | 2220 | 2220 |
Provisional Weights (kg) | |||||
---|---|---|---|---|---|
Wheelbase | WB | 3410 | 4060 | 4660 | 4990 |
Cab type | day | day | day | day | |
Vehicle Mass Unladen | Front | 2295 | 2320 | 2430 | 2393 |
Rear | 1215 | 1280 | 1250 | 1312 | |
Total | 3510 | 3600 | 3680 | 3705 | |
GVW | 11000 | 11000 | 11000 | 11000 | |
Max. Permissible Trailer Weight | 3500 | 3500 | 3500 | 3500 | |
Payload Allowance (Body & Payload for Chassis Cab) | 7490 | 7400 | 7320 | 7295 |
CAB FEATURES | |||
CAB EXTERIOR | CAB INTERIOR | ||
Type | Hexapod, white all-steel with roof outline markers. | Features | Flame-resistant interior trim. Vinyl floor matting. Dual long grab handles each side. Interior fluorescent lighting. Driver and passenger SRS airbags |
Features | Manual tilt to 45 deg. Tinted windscreen. Chrome radiator grille. Plastic resin non-slip entry steps. 90 deg. opening doors. Zinc galvanised frame structure. All steel front bumper with fog and daytime running lamps. Two halogen head lamps with indicators. Front mudguards with spray suppression. Aluminium rear under run bar protection (R58.03) | Storage Space: | Centre seat back compartment, twin overhead lockers, centre tray, door and dashboard pockets. |
Seats: Features: | Driver’s fully adjustable Isringhausen® air-suspended seat with head restraint and 3-point seat belt with pretensioner. Rigid centre seat with 2-point seatbelt. Rigid passenger seat with head restraint and 3-point seat pretensioner. Upholstery shade upgrade. | ||
Vision: Features: | Large door-mounted heavy adjustable mirrors. Front underview mirror and kerb mirror. Driver and passenger sun visors. Deep cut side windows to reduce blind spots. Electric windows with driver control and lock. |
SAFETY & SECURITY | |
R29 cab strength: | Complies with ECE-R29 cab strength standard |
Central locking: | Central locking with remote keyless entry and immobiliser |
Lane departure warning system: | Stereo camera monitor, alerts driver with a warning buzzer and LCD monitor. |
Advanced Emergency Braking System (AEBS): | Utilised stereo camera system to reduce collision damage |
